功用与详细资料/Brief Introduction：

全全主动设备液压泵式膏体酱灌装线设备机我公司适宜股票市场需要量研发的新企业产品。该机型通过SUS304不銹钢液压泵式压力容器检验泵制定灌装线设备，且集全主动设备上盖、全主动设备旋盖、汽车电器电器设备为一体化，划算有用，征占面积计算小，广泛采用采用于药业有限公司、面制品、化肥、化工厂、彩妆品等制造业的液滴封装，满足GMP标准规范要求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

作用/characteristic：

◆用注塞泵式计量检验泵审理分装，可用于各项黏黏度介质液体，高精准较高；泵的机购用快接式拆开机购，更方便除污、杀菌消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆注塞泵式计量检测泵活赛环板材可根据业及粘液组成成分的与众不同采取硅再生胶，四氟氯乙烯或别的板材，特俗时候采取陶瓷图片板材。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC调节系统，调频变频调速，自行化程度上高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不包装，定时运算的功能。Lack of bottle filling, automatic counting function◆装量变动方便快捷，可是一次变动都是检定泵的充填量，也可针对于不同的检定泵去微幅变动；运行简单便捷，变动高速 。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆罐装针头配有防漏滴设备，充填时潜泳到瓶底罐装，缓缓提升，放到泡沫。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆组装机可可用于有差异 技术参数的塑料瓶子，优化便捷，可在多日间内成功完成。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆整个设备按GMP的标准设汁。The machine designed according to the requirements of GMP

能力参数表/technic parameter：

可用于矿泉水瓶尺寸规格Size of bottles	20-1000ml（会根据必须订制）20-1000 - ml (according to your need）
常用水瓶座口径Apply the bottle diameter	¢20-¢150mm
适用于盖子年纪Apply the lid specifications	¢20-¢70mm
种植水平 production capacity	四头装罐：1000-2500瓶/小时左右 Four filling head: 1000-2500 bottles per hour 八头灌装线：2500-4000瓶/小 Eight head filling: 2500-4000 bottles per hour 12头灌装生产线：4000-6000瓶/小时英文 12 head filling: 4000-6000 bottles per hour
装量精度The load error	±1%
旋盖达标率Screw cover percent of pass	≥99%
供电power supply	380V，50HZ
电率power	3.0KW
氧气源gas sources	0.4-0.75MPA
效率有效控制speed control	直流变频空调可控硅调压variable speed
