使用用途与百度百科/Brief Introduction：

机器是所代替口服药方式液夹层瓶子的新类产品，基本防止出现办法了往往口服药方式液夹层瓶子的不健康目的。该种灌封机采用的塑料材质瓶，不当不须得洗瓶机、烘干设备机，更不须得清洁，就能够单独灌封。机用户全会自动理瓶、进瓶、罐装，罐装量相对不稳定性，无漏滴，无瓶不罐装。上盖、密封率可以达到100%。此机的技术现进，面积小、执行相对不稳定性、躁音低，实操抢修、除污便捷等亮点，基本遵循GMP规范。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本形号有低挡和快速路两大类生产量供您选取。Note: this model has two kinds of low speed and high-speed production for your choice.

的特点 Characteristic

◆机器支持于不同易折瓶口服药液计量检验灌装线和封好。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆各个机械元器件封装均用到知时尚厂家牌厂家。All electrical components adopt famous brand◆超声波焊接机进行形象化有利，无瓶不罐装，量值溯源*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折泡沫塑料饮料瓶灌封机的关键型式与关键技术Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型内服液易折塑胶片瓶灌封机其主要理瓶器、理盖器、主自动化机械传动平衡仪器、同时进行带宽度送单瓶置、玻璃瓶子检漏平衡仪器、灌装线单位、筛选平衡仪器、热熔胶封单位、气动平衡自动化机械手指头夹瓶单位、步进驱动器无刷电机宽度上瓶单位与出瓶单位等构成的。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆机子的使用的口服药液易折塑料管瓶、盖一定整洁区加工的，应该由药粉材执照书证，因为瓶身与底盖经传送和"去负责"后可可以直接进人灌封间。在理盖器、理瓶器的自行专向翻整，消除倒置底盖及瓶身底口朝下的瓶，使专向后的包材喂料有規則地进人卸料导轨中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定向招生后冲剂液易折金属瓶在推送轨道交通里排Directional oral liquid after folding plastic bottles in conveying rail out easily

的技术数据technical parameters：

型号model	NLGFY-40	NLGFY-80
装量条件The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
封口处率Hot sealing intensity	》99%
装量偏差The load error	《1.5%
划伤率damage rate	《1.0%
输出power	2KW	3KW
电源适配器Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
重 Weight	700Kg	800Kg
