功能与概况/Brief introduction:

远程服务器是在人才引进和获取日式先进典型技木的核心上，我子公司服务性研发管理的一种专注共性口服方式液和糖浆的装灌、上塞、旋（轧）盖机。远程服务器选用日式全进囗的高精确封闭性式凸轮机构量程卡位器，精确高，程序运行耐用，动用安全使用年限长。该量程器成分简单易行，不断动用不要处理。机器重要适于于各样口服方式液及糖浆体体的装灌、压塞及旋（轧）盖，多方面多方面用作食物、制药业、医药化工的行业及科学研究研究方向。基本达到祖国GMP追求。NFGX-30/100 Automatic Oral&sSyrup Filling&rotation (rolling) machine is built in the absorption of foreign advanced tecnology, based on independently developed by the company ,It is the domestic leading level.This machine is suitable for oral and syrup liquid filling&capping. Widely used in food, pharmaceutical, chemical industries and scientific research.Full compliance with the GMP requirements.

特征 /Characteristic：

◆人与机器软件界面调整、的操作更直观便宜、PLC控制，装量*。Human-machine interface settings, an easy and intuitive, PLC control.◆直流变频空调把控好、工作速率中任何调接、自主数值。Frequency control, the production rate be adjusted automatically count. ◆自主停止工作，无瓶不灌装生产线。No bottle no filling. ◆高精确气缸精度等级计有效控制，确定*。High-precision cam meter control, precise positioning◆选用SUS304及316L冷库保温隔热板的表层制造厂，是完全适用GMP想要。SUS304 and 316L stainless steel, full compliance with GMP requirements.

技术性性能指标/ technical parameters：

装量区间Filling volume	30-150ML
装量随机误差loading error	≤ ±1%
旋（轧）盖合理率Rotation (rolling) Cover pass rate	≥99%
生产方式学习能力 Production capacity	30-60瓶/分 钟&nb꧑sp; 减速 70-100瓶/分 钟 &nbsܫp;   快速 30-60 bottles / min  70-100 bottles / min
主机电源Power	380V/50Hz
输出功率Power	2.0 kw
丝机重量Net weight	600 kg
外观形状的尺寸Dimension	2000*1000*1500mm
